Custom Silicone Chocolate Mold Manufacturing Guide

A custom chocolate mold starts with the finished chocolate, not with a generic silicone tray.

The manufacturer needs the bar or bonbon geometry, target piece weight where relevant, visible surface finish, artwork, cavity count, filling method and target food-contact market before the master and production mold are finalized.

Send:

• bar/bonbon/custom shape
• dimensions
• target grams
• logo/artwork
• surface finish
• cavity count
• tray-size limits
• filling method
• destination market

Vector artwork or STEP/STP is preferred.

If only a photo/sketch exists, 3D modeling may be required.

Simple 3D modeling is typically around USD 50 when straightforward.

Use target grams + actual chocolate/process as the validation gate.

CAD volume is a design input, not a guaranteed final weight.

Silicone reproduces the master.

For very high-gloss commercial chocolate, rigid polycarbonate tooling may be a better option in some applications.

Review:

• feature depth
• line width
• spacing
• corner radius
• draft
• chocolate thickness around the feature

Possible master routes can include:

• CNC
• additive
• existing physical master
• hybrid process

Choose based on geometry, finish and accuracy.

Confirm:

• selected grade
• intended food use
• destination market
• color/formulation if relevant
• available report scope

Validate:

• grams
• release
• surface
• logo
• cavity shape
• tray handling
• real chocolate process

After one cavity is approved:

• set pitch
• cavity count
• tray dimensions
• support
• handling

Keep:

• approved revision
• master/tool record
• material
• cavity count
• approved sample

Can you design the mold from the target chocolate weight?

Yes, but validate final grams with actual chocolate.

Can I approve the logo before the production mold?

Yes.

Can you make a small first production order?

Applicable RTV production can start from 20 molds per approved design.

Does silicone automatically create a glossy chocolate?

No.

Is polycarbonate always better?

No. It depends on the product/process.
